Technical feature: This equipment is integrated with machine, electricity and gas. PLC Controlling, It is pushed by servo motor.
The main power component is modular assembled.
Necessary machine for steel towers—Drilling for Angle bar, Stamping, there are three modulus in each side of CNC auto production line, can machining angle bars with range
This machine is necessary machine for the steel tower—Punching holes for Angle bar, Stamping, cutting, CNC auto production line…
Range of angle bar: 63*63*4mm~200*200*20mm
Max capacity for punching hole: φ26*20mm
1. Exterior Dimension (mm): 38000x2400x2700.
2. Weight (Ton): 20.
Vertical screw conveyor: conveyor capacity: 60t/h, power: 4kw,
Horizontal screw conveyor: conveyor capacity: 60t/h, power: 3kw;
Conveyor belt: conveyor capacity: 20t/h, power: 4kw;
Pill: first time load capacity: 4000kg, diameter: 0.8-1.2mm;
Wind capacity: total wi...
Application for H BEAM Dimension: Web height: 350-1500mm, Web Thickness: 6-35mm,
Flange Width: 250-800mm, Flange Thickness: 15-60mm
Dimension of work piece: superposition thickness of material is 80mm,
Width*length: 1000mm*1650mm per piece
825mm*1000mm two pieces, 500mm*825mm four pieces;
Main shaft: Quick-changing tap holder,
Power Source: 380V/50Hz
Environment temperature: -10~40 degree
Welding Speed: 250-2500mm/min,
Max empty walking speed: 3000mm/min
Dia of Welding wire: 3.2-5mm
Solder Tank Capacity of Callback Machine: 50kg,
Capacity of the welded wire plate rack: 50kg,
Total power of the equipment: 70kw.
Flange width: 150-800mm, Flange thickness: 6-40mm
Web height: 200-1800mm, Web thickness: 6-32mm;
Length of work piece: 4000-15000mm;
Voltage of Power Source: 380V/ 50Hz;
Mechanical Power: 12KW,
Rated Input Power: 28KW,
Limited for short material: machining mix material is no less than 2700mm by automatic, by manual is 690-2700mm,
Diameter of machining holes: vertical shaft 12.5-33.5mm, horizontal shaft: 12.5-26.5mm
Y shaft Max journey for single cutter is 2.2m, X shaft journey=path-main machine slide way-220mm,
Cutting Speed: 50-3000mm/min,
